Core Specifications

• Printing Method: Direct thermal (no ink or ribbon required)
• Print Speed: Up to 200 mm/sec for efficient receipt generation
• Resolution: 203 DPI for clear text and barcode output
• Paper Width: 80 mm standard (actual: 79.5 ± 0.5 mm)
• Print Width: Approx. 72 mm usable area
• Auto Cutter: Partial cut for clean receipt separation

Connectivity & Interfaces

• USB Port: Standard USB 2.0 for direct PC or POS terminal connection
• Cash Drawer Port: RJ11 interface (24V/1A) for automatic drawer triggering
• Command Set: ESC/POS compatible for universal POS software integration

Physical & Build Details

• Dimensions: Compact footprint suitable for desktop POS setups
• Weight: Lightweight for easy installation and relocation
• Material: Durable ABS plastic housing
• Certifications: CE, FCC, RoHS – compliant with international standards

Functional Features

• Character Sets:
• ANK: Font A & B for standard and compact text
• Chinese: Simplified & Traditional (24×24 dot matrix)
• Barcode Support:
• 1D: UPC-A, UPC-E, EAN-13, EAN-8, CODE39, ITF, etc.
• 2D: QR Code, PDF417 – suitable for modern POS and inventory systems
• Paper Sensor: Detects paper end for uninterrupted operation

Operational Efficiency

• Print Head Life: Up to 100 km of printed output
• Power Input: AC 100–240V; Output: DC 24V/2.0A
• Energy Saving: Low power consumption, ideal for high-volume environments

Ideal Use Cases

• Retail POS systems
• Restaurants and cafés
• Pharmacies and clinics
• Supermarkets, bookstores, and telecom shops
