Core Specifications

• Print Technology: Direct thermal (no ribbon required)
• Print Speed: Up to 5 ips (127 mm/sec)
• Resolution: 203 DPI
• Max Print Width: 104 mm
• Max Print Length: 1,000 mm
• Sensors: Transmissive (fixed), Reflective (adjustable), Head Open

Media Handling

• Media Types: Gap, Black Mark, Notch, Fan-Fold, Continuous
• Media Width: 15–118 mm
• Media Thickness: 0.06–0.20 mm
• Roll Diameter: Up to 127 mm
• Core Diameter: 25.4–38.1 mm
• Paper Loading: Easy top-load design with adjustable guides

Connectivity Options

• Standard Interface: USB 2.0
• Optional Interfaces: USB + Serial + Ethernet
• Software Compatibility:
• Drivers: Windows, Linux, Mac
• Utilities: Label Artist-II™, Bartender Ultralite
• Emulations: SLCS™, BPL-Z™, BPL-E™, BPL-D™

Functional Features

• Programming Language Switching: Smart auto-switch without manual mode setting
• User Interface: Single LED for status indication
• Maintenance: Toolless replacement of print head and roller
• Optional Add-ons: Peeler, external paper supply

Physical & Environmental Specs

• Dimensions: 181 × 168 × 155 mm (W × D × H)
• Weight: 1.7 kg
• Operating Temperature: 0–40°C
• Storage Temperature: -20–60°C
• Humidity: Operating 10–80% RH; Storage 10–90% RH
• Power Supply: External adapter, 100–240V AC, 50/60Hz

Barcode & Font Support

• 1D Barcodes: UPC-A/E, EAN-13/8, CODE39, CODE128, ITF, MSI, POSTNET, etc.
• 2D Barcodes: QR Code, PDF417, Data Matrix, MaxiCode, Aztec, Codablock, Code49
• Fonts: Bitmap, Scalable, Unicode (UTF-8, UTF-16LE/BE), Code Pages

Ideal Use Cases

• Logistics and shipping labels
• Warehouse inventory tagging
• Healthcare specimen and patient ID
• Manufacturing asset labeling
• Retail shelf and product labels
