Core Specifications

• Printing Method: Direct thermal (no ink or ribbon required)
• Print Speed: Up to 250 mm/sec for high-speed receipt generation
• Resolution: 203 DPI; supports 576 or 512 dots/line for sharp output
• Print Width: 72 mm usable area
• Paper Width: 79.5 ± 0.5 mm standard thermal paper
• Auto Cutter: Partial cut for clean and consistent receipt separation

Connectivity & Interfaces

• LAN Port: Ethernet interface for network-based printing
• Cash Drawer Port: RJ11 (DC 24V/1A) for automatic drawer triggering
• Command Set: ESC/POS compatible for universal POS software integration
• Multi-Terminal Support: Enables printing from multiple devices over LAN

Physical & Build Details

• Dimensions: 184 × 140 × 135 mm (D × W × H)
• Weight: Approx. 1.0 kg – compact and lightweight
• Material: Durable ABS plastic housing
• Certifications: CE, FCC, RoHS – compliant with international standards

Functional Features

• Character Sets:
• ANK: Font A (12×24 dots), Font B (9×17 dots)
• Chinese: Simplified & Traditional (24×24 dot matrix)
• Barcode Support:
• 1D: UPC-A, UPC-E, EAN-13, EAN-8, CODE39, ITF, CODABAR, CODE93, CODE128
• 2D: QR Code, PDF417
• Code Page Support: Includes PC347, Katakana, PC850, PC860, PC863, PC865, WPC1252, PC866, PC852, PC858, Arabic, Hebrew, Greek, Cyrillic, and more
• Buffer Memory:
• Input Buffer: 64 KB
• NV Flash: 256 KB
• Paper Sensor: Detects paper end for uninterrupted operation
• Error Alerts: Visual and audible indicators for paper or connection issues

Operational Efficiency

• Print Head Life: Up to 150 km of printed output
• Cutter Life: Rated for 1.5 million cuts
• Power Supply:
• Adapter: AC 110V/220V, 50–60Hz
• Output: DC 24V/2.5A

Environmental Conditions

• Operating Temperature: 0–45°C; Humidity: 10–80% RH
• Storage Temperature: -10–60°C; Humidity: 10–90% RH

Ideal Use Cases

• Retail POS systems (multi-terminal environments)
• Restaurants and kitchens (LAN-based kitchen order printing)
• Pharmacies, clinics, and service counters
• Supermarkets, bookstores, and telecom shops
